Kev Nyab Xeeb Breaker McCB 3P

Lub hauv paus ntsiab lus ua haujlwm ntawm kev nyab xeeb breaker mccb 3p yog raws li kev sib xyaw ua ke ntawm kev sib nqus thiab cov pa thermal. Thaum muaj ntau dhau los yog Circuit Court tshwm sim hauv Circuit Court, qhov tam sim no yuav nce siab dua, thiab cov cim sib nqus yuav txiav txim siab qhov txawv txav no thiab txiav kom sai ntawm Circuit Court. Lub caij no, cov cua nab kuab kuaj ntsuas qhov kub thiab txias dua ntawm qhov ntsuas kub tshaj qhov teeb meem kub tshaj cov khoom siv lossis kev sib tsoo hluav taws.

Qauv:STN2-100

Xa lus nug

Product Description

Cov lus qhia	STN2-100				STN2-160				STN2-250				STN2-400				STN2-630
Ncej Tam Sim No (A)	100				160				250				400				630
Tus naj npawb ntawm tus ncej	3		4		3		4		3		4		3		4		3		4
Qhov kawg breaking muaj peev xwm (ICU, ka)	F	N		H	F	N		H	F	N		H	F	N		H	F	N		H
AC220 / 240V (los ntawm)	85	90		100	85	90		100	85	90		100	40	85		100	40	85		100
AC380 / 415V (Ka)	36	50		70	36	50		70	36	50		70	36	50		70	36	50		70
Ntsuas cov ntaub ntawv rwb thaiv tsev voltage	AC800V
Cov Chaw Ua Haujlwm Ntsuas Ua Haujlwm	AC690V
Rated tam sim no, thermal tripping, TMD, a	63, 80, 100				80, 100, 125, 160				125, 160, 200, 250				-				-
Rated tam sim no, hluav taws xob Tripping, mic, a	40, 100				40, 100, 160				100, 160, 250				250, 400				250, 400, 630
Ntu, ceeb toom, txhaum Tej ntxiv	Lossis / sd / sde / sdx
Shunt & under voltage coil	Mx / mn
Neeg Kho Tshuab Lub Neej	50000				40000				20000				15000				15000
Lub Neej Hluav Taws Xob	30000				20000				10000				6000				4000

Kev Nyab Xeeb Breaker McCB 3P / 4P Refects Lub cev txwv tshiab tam sim no thiab kev tsim khoom siv thev naus laus zis, muaj kev sib xyaw ua ke, high breaking, thiab xoom yooj yim. Circuit Court breaker yog nruab nrog overload, luv-circuitf thiab undervolters kev tiv thaiv ntaus ntawv, yog li tiv thaiv cov khoom siv hluav taws xob thiab hluav taws xob kev puas tsuaj los ntawm kev puas tsuaj.

Khoom nta

Bipolar Tsim: McCb 3P / 4P yog qhov tsim Bipolar, uas txhais tau tias nws tuaj yeem tswj hwm ob lub sijhawm xoom thiab hluav taws kub tib lub sijhawm, kom muaj kev nyab xeeb thiab ruaj khov ntawm Circuit Court.

Siab Precision: Nrog Rau Cov Kev Ntsuas Siab Tam Sim No, nws tuaj yeem txiav txim siab txiav txim ua haujlwm, qhov teeb meem kev txhaum hauv Circuit Court thiab txiav tawm ntawm Circuit Court raws sijhawm.

Muaj kev ntseeg siab: ua nrog cov thev naus laus zis siab thiab muaj kev ntseeg siab thiab ruaj khov, thiab tuaj yeem ua haujlwm ib txwm muaj nyob hauv ntau qhov chaw hnyav.

Yooj yim rau nruab thiab tswj hwm tsim nyog, yooj yim rau nruab, thiab tib lub sijhawm yooj yim los tswj thiab hloov pauv cov neeg siv ua haujlwm.
