High break Muaj Peev Xwm McB 6ka

Lub siab breaking muaj peev xwm MCB 6ka yog tus neeg txhaum hluav taws xob me me tsim los muab kev tiv thaiv hauv Circuits luv luv txog 6000 amperes. High breakable muaj peev xwm MCB 6ka muaj peev xwm sai sai tawm lub zog hluav taws xob xws li muaj kev txawv txav lossis kev tiv thaiv luv luv, yog li tiv thaiv cov cuab yeej thiab cov neeg ua haujlwm hauv Circuit Court.

Qauv:STM22-63

Xa lus nug

Product Description

Tus qauv	STM22-63
Lub hom phiaj	Iec60898-1
Tus ncej	1p, 2p, 3p, 4p
Tripping nkhaus	B, c, d
Rated luv-circuit muaj peev xwm (icn)	3KA, 4.5ka, 6ka
Rated tam sim no (hauv)	1,2,4,6,16,20,25,32,40,50,63a
Ntsuas voltage (un)	AC230 (240) / 400 (415) V
Sib Nqus Tawm	B nkhaus: nruab nrab ntawm 3in thiab 5 hauv C Nkhaus: Ntawm 5in thiab 10in D Nkhaus: Nruab nrab ntawm 10in thiab 14in
Electro-tshuab xaus	Tshaj li 6000 toj

Kev tsis muaj

 Tam sim no muaj nuj nqi tam sim no: Qhov ntsuas cov lus qhia tam sim no feem ntau yog nruab nrab ntawm 1a thiab 63a nyob ntawm seb cov qauv thiab tshwj xeeb.

 Ntsuas Voltage: Feem ntau 230V / 400v (AC), tab sis kuj tseem muaj rau DC voj voog.

Baring Muaj peev xwm: 6000a (nyob rau qee yam kev mob, piv txwv li thaum lub Circuit Court tam sim no tsis tshaj tus nqi no).

 Neeg Kho Tshuab Lub Neej: Feem ntau txog li 20,000 zaus lossis ntau dua.

 Lub Neej Hluav Taws Xob: feem ntau yog kwv yees los ntawm ntau txhiab tus kaum ntawm ntau txhiab mais ntawm cov voj voog, nyob ntawm cov xwm txheej ntawm kev siv thiab chaw tsim khoom cov kev qhia tshwj xeeb.

Cov yam ntxwv tseem ceeb

Muaj peev xwm loj breaking: Lub peev xwm rhuav tshem ntawm 6ka txhais tau tias kev siv hluav taws xob loj no tuaj yeem tiv thaiv cov voj voog uas muaj kev tiv thaiv nyob rau lub sijhawm txawm tias muaj kev cuam tshuam huab.

Ntau yam tshwj xeeb muaj: ntau yam ntawm cov specifications thiab qauv ntawm kev kub siab breaking mcb (1p, 2p, 4p, 4P), thiab lwm yam kom tau raws li cov kev xav tau ntawm cov kev xav tau sib txawv.

Siv dav: Cov chaw sib txuas lus Circuit Court tau siv dav hauv lub zog hluav taws xob, chaw lag luam los muab kev tiv thaiv ntau yam khoom siv hluav taws xob thiab cov hluav taws xob.

High Breaking Capacity MCB 6KA
